12.5T Compression Refuse Vehicle
12.5T Pure Electric Compression Refuse Collector
8.5m³ High-Capacity Compactor Body
142.19kWh Lithium Iron Phosphate Battery
Carries Up to 180 Standard 240L Bins
270km Driving Range with Fast Charging
Compatible with 240L, 660L and Optional 300L Bins
The Electric Waste Collection Truck is purpose-built for high-volume municipal sanitation and commercial waste collection. Developed on a self-designed 12.5-ton electric chassis, it combines intelligent vehicle integration, a high-capacity hydraulic compaction system, fast charging technology, and zero-emission performance. The integrated body structure improves durability while simplifying maintenance, making it an efficient solution for cities, industrial parks, airports, hospitals, residential communities, and environmental sanitation contractors.
Electric Waste Collection Truck Overview
The Electric Refuse Collection Vehicle integrates the chassis and refuse body into one optimized structure, delivering improved stability, easier servicing, and reliable daily operation. Intelligent electronic controls enhance vehicle management while reducing operating complexity for sanitation fleets.
Electric Waste Collection Truck with Intelligent Integration
The integrated design improves structural strength and optimizes vehicle performance. Furthermore, the intelligent control system continuously monitors operating conditions to improve efficiency and safety.
Key features include:
- Integrated body and chassis
- Intelligent electronic control
- Fast charging capability
- Comprehensive safety configuration
- Stable hydraulic operation
- Reliable performance in extreme climates
Electric Waste Collection Truck for High-Efficiency Collection
The advanced hydraulic system allows loading and compression to operate simultaneously, improving daily waste collection efficiency.
Operational benefits include:
- Simultaneous loading and compaction
- Continuous operating cycles
- High compression efficiency
- Low operating noise
- Stable hydraulic performance
The 8.5m³ refuse body accommodates approximately 180 fully loaded 240L waste bins, carrying around 6 tons of compressed waste during daily operations.
Electric Waste Collection Truck with Reliable Sealing
The fully enclosed refuse body helps prevent sewage leakage and odor during transportation. In addition, standardized welding and precision assembly improve overall vehicle consistency and long-term durability.
Sealing features include:
- Corrosion-resistant sealing strips
- Fully enclosed compactor cover
- Anti-leak body construction
- Sewage collection system
- Standardized welding process
- Corrosion-resistant refuse body
Electric Waste Collection Truck with Long Operating Range
Powered by a 142.19kWh Gotion High-tech lithium iron phosphate battery, the vehicle delivers stable performance for demanding municipal collection routes.
Performance highlights include:
- 142.19kWh battery capacity
- Permanent magnet synchronous motor
- 120kW rated power
- 200kW peak power
- 270km driving range
- Approximately 35-minute fast charging
- Maximum speed of 90km/h
Applications
Suitable for:
- Municipal sanitation departments
- Residential communities
- Industrial parks
- Commercial districts
- Airports
- Hospitals
- Universities
- Logistics centers
- Environmental sanitation companies
- Smart city waste management projects
Optional Configurations
Available options include:
- Standard dual 240L bin lifter
- Standard 660L bin lifting mechanism
- Optional 300L metal bin lifter
- Optional semi-sealed hopper
FAQ
What is the refuse body capacity?
The vehicle features an 8.5m³ refuse body capable of carrying approximately 180 standard 240L waste bins or around 6 tons of compressed waste.
How far can the truck travel on one charge?
The vehicle provides a driving range of approximately 270km under constant-speed operating conditions.
Which waste bins are supported?
The standard lifting mechanism supports 240L and 660L plastic bins, while a 300L metal bin lifter and semi-sealed hopper are available as optional equipment.
Is the vehicle suitable for municipal sanitation fleets?
Yes. It is designed for municipal sanitation departments, residential communities, industrial parks, airports, hospitals, commercial districts, and environmental service providers.
Conclusion
The Electric Waste Collection Truck combines a self-developed electric chassis, intelligent control system, efficient hydraulic compaction, and an 8.5m³ refuse body into a dependable sanitation solution. Its large loading capacity, 270km driving range, fast charging capability, and multiple bin-lifting options help improve collection efficiency while supporting zero-emission urban waste management. Contact us to learn more about customization options and global export services.
Product Specifications
| Item | Specification |
|---|---|
| Vehicle Model | CL5125ZYSBEV |
| Chassis Model | CL1120JBEV |
| Gross Vehicle Weight | 12,495 kg |
| Curb Weight | 7,960 kg |
| Payload | 4,340 kg |
| Overall Dimensions | 7,680 × 2,430 × 2,630 mm |
| Wheelbase | 3,800 mm |
| Battery Type | Lithium Iron Phosphate |
| Battery Brand | Gotion High-tech |
| Battery Capacity | 142.19 kWh |
| Motor Type | Permanent Magnet Synchronous Motor |
| Rated / Peak Power | 120 / 200 kW |
| Rated / Peak Torque | 200 / 500 Nm |
| Maximum Speed | 90 km/h |
| Driving Range | 270 km |
| Charging Time | Approximately 35 min (30%–80% SOC) |
| Refuse Body Capacity | 8.5 m³ |
| Packer Capacity | 0.7 m³ |
| Packer Sewage Tank | 340 L |
| Side Sewage Tank | 360 L |
| Loading Cycle | ≤15 s |
| Full Compression Cycle | ≤45 s |
| Bin Lifting Cycle | ≤10 s |
| Hydraulic Pressure | 18 MPa |
| Standard Bin Lifter | Dual 240L Plastic Bins & 660L Bin Lifter |
| Optional Equipment | 300L Metal Bin Lifter, Semi-Sealed Hopper |
