China 50T 40FT Container Loading Skeleton Trailer | Chengli Factory

factory good price chengli Overview.

factory good price chengli is an important factor in commercial vehicle safety.

Introduction.

Chengli is a professional manufacturer of 50T 40FT container loading skeleton trailers in China. Our factory supplies heavy duty skeleton semi trailers at competitive prices. The trailer is designed for container transport with high strength structure and reliable performance.

We have extensive experience in semi trailer production. Our skeleton trailers meet international quality standards. Each trailer undergoes strict inspection before delivery.

Key Features.

The Chengli 50T skeleton trailer combines durability with efficient design. Key features include:.

• 50 ton payload capacity for 40FT containers.
• Heavy duty I beam main structure with Q345B high tensile steel.
• 12 units twist locks for secure container fixing.
• 3 axle Fuwa suspension system.
• Mechanical reinforced leaf spring suspension.
• Dual line pneumatic braking with emergency relay valve.
• Complete chassis sandblasting and anti-corrosion painting.

Performance and Configuration.

The main beam uses heavy duty I beam design welded by automatic Submerged-Arc processes. The steel grade is Q345B high tensile material. This ensures extra durability and resistance to stress during heavy container transport operations.

The frame beam specifications include top flange 14mm with width 140mm. Middle flange 8mm, and bottom flange 16mm with width 140mm. Main beam height is 500mm. These dimensions provide optimal strength-to-weight ratio for a 50T payload.

The trailer is equipped with 3 axles using Fuwa brand. Each axle is rated at 13 tons with 16 ton brake pads. The landing gear has 28 ton lifting capacity with two speed operation. King pin option is 2.00 or 3.5 inch bolt-in type.

The mechanical suspension uses reinforced leaf springs with 90mm width and 13mm thickness. There are 10 leaf layers. The pneumatic braking system is dual line type with T30 air chambers and 40L air tanks. Emergency relay valve is included for safety.

Tire specification is 12R22.5 with 12 pieces. Rims are 9.0-20 size. The trailer comes with one standard toolbox and one spare tire rack.

The electrical system is 24 volt with 7 pin connector. Lights include parking stop, reverse, number plate and indicator. Rear lights conform to European standard. Front side reflectors and rear reflectors are installed.

The painting process includes complete chassis sandblasting to remove rust. One coat of anticorrosive prime is applied followed by two coats of final paint. This ensures long lasting surface protection.

Applications.

The 50T skeleton trailer is designed for container loading and transportation. It supports 40FT standard containers. The trailer is suitable for port operations, logistics distribution, and freight transport on highways.

The lightweight design with 6.5T tare weight maximizes payload efficiency. The 12.38m length and 2.48m width accommodate standard container dimensions. This skeleton trailer is widely used in international freight and domestic logistics chains.

Why Choose This Truck.

Chengli factory offers direct pricing without middleman markup. The 50T skeleton trailer is built with proven materials and components. Fuwa axles and reinforced suspension ensure long service life.

We support shipping by bulk cargo, RORO, or 40HQ container. Each trailer is inspected before loading. Contact our factory for detailed specifications and current pricing.
