FAW 12T Car Carrier Truck with Trailer
A medium-duty diesel cargo truck designed for commercial transport operations.
Built on a FAW chassis with multiple engine options.
Configured with a 4×2 drivetrain and EURO 6 compliant diesel engines.
Suitable for logistics, cargo distribution, and general freight transportation.
| Item | Specification |
|---|---|
| Vehicle Type | Cargo Truck |
| Drive Type | 4×2 |
| Chassis Brand | FAW |
| Chassis Model | CA1120P40K46L5BE6A84 |
| Overall Dimensions (mm) | 8440 × 2500/2550 × 3600/3700 |
| Gross Vehicle Weight (kg) | 11995 |
| Payload Capacity (kg) | 5800 / 6300 |
| Curb Weight (kg) | 5500 / 6000 |
| Cabin Capacity | 3 Persons |
| Wheelbase (mm) | 4400 / 4700 |
| Front / Rear Overhang (mm) | 1155 / 2585 |
| Approach / Departure Angle | 20° / 16° |
| Front Axle Load (kg) | 4360 |
| Rear Axle Load (kg) | 7635 |
| Number of Axles | 2 |
| Tire Specification | 245/70R19.5 16PR, 8.25R20 16PR |
| Number of Tires | 6 |
| Front Track (mm) | 1706 / 1750 / 1812 |
| Rear Track (mm) | 1678 / 1740 / 1800 |
| Fuel Type | Diesel |
| Emission Standard | Euro VI |
| Fuel Consumption (L/100km) | 21.1 |
| Max Speed (km/h) | 95 |
| ABS | Equipped |
| Engine Model | D40TCIF1 |
| Engine Displacement | 4.1L |
| Engine Power | 135 kW |
| Horsepower | 185 HP |
| Engine Model | CA4DH1-18E6 |
| Engine Displacement | 3.8L |
| Engine Power | 132 kW |
| Horsepower | 180 HP |
| Engine Model | WP4.1NQ190E61 |
| Engine Displacement | 4.1L |
| Engine Power | 140 kW |
| Horsepower | 190 HP |
| Engine Model | CA4DD2-18E6 |
| Engine Displacement | 3.2L |
| Engine Power | 132 kW |
| Horsepower | 180 HP |
| Engine Model | H33-180E60 |
| Engine Displacement | 3.3L |
| Engine Power | 130 kW |
| Horsepower | 177 HP |
Built on a reliable FAW heavy-duty chassis for stable cargo transportation.
Available with multiple engine options to match different transportation needs and market requirements.
Large cargo capacity makes it suitable for logistics, distribution, industrial transport, and general freight operations.
Reinforced steel body structure improves durability and long-term performance.
Equipped with ABS braking system for improved driving safety and control.
Multiple tire and suspension configurations available for different road conditions.
Fuel-efficient diesel engines help reduce operating costs during long-distance transportation.
Optional cab styles and exterior designs available for different customer preferences.
This product is a medium-duty cargo transport truck for commercial logistics operations.
It integrates a diesel-powered chassis with cargo carrying capability.
The vehicle is designed for regional freight and distribution transport tasks.
Typical Applications
Used for general cargo transportation and logistics distribution services.
Applicable in industrial material delivery and commercial freight operations.
Suitable for urban and regional transport applications.
Key Technical Characteristics
The vehicle has a gross vehicle weight of 11995 kg with rated payload capacities of 5800 kg and 6300 kg.
It is built on a FAW CA1120P40K46L5BE6A84 chassis with wheelbase options of 4400 mm and 4700 mm.
Engine options range from 177 hp to 190 hp with diesel engine displacements between 3.2L and 4.1L.
The vehicle complies with GB17691-2018 China VI emission standards and has a maximum speed of 95 km/h.
Configuration & Selection Guidance
Multiple engine configurations are available according to load and transport requirements.
Wheelbase selection can be adapted for maneuverability or cargo capacity preferences.
Optional cab and exterior appearance configurations are available with the chassis platform.
Tire specifications include 245/70R19.5 16PR and 8.25R20 16PR configurations.
Safety & Operational Considerations
The vehicle is equipped with an anti-lock braking system for operational safety.
Side protection structures use Q235 material with welded mounting configuration.
The rear protective structure is integrated into the vehicle body design.
Routine inspection of braking, suspension, and load-bearing systems is recommended.
Recommended Configuration
Select higher horsepower engine configurations for heavy-load transport operations.
Choose wheelbase configuration according to cargo distribution and road conditions.
Maintain standard tire specifications for load stability and driving performance.
Use ABS-equipped braking systems for improved operational control and safety.
Conclusion
This FAW medium-duty cargo truck provides a practical solution for freight transport operations.
It combines diesel-powered performance with multiple chassis and engine configuration options.
The design supports commercial logistics and cargo transportation applications.
Q: What kind of transportation jobs is this truck suitable for?
A: It is ideal for logistics, cargo delivery, industrial transport, and regional freight operations.
Q: Does this truck offer good fuel economy?
A: Yes. The diesel engine options are designed to balance strong power with low fuel consumption.
Q: Is the truck suitable for long-distance transportation?
A: Absolutely. The durable FAW chassis provides stable and reliable highway performance.
Q: Can I choose different engine configurations?
A: Yes. Multiple engine brands and horsepower options are available for different markets and applications.
Q: Is the truck durable enough for heavy daily use?
A: Yes. The reinforced body structure and heavy-duty chassis are built for demanding commercial operations.
Q: Does the truck provide good driving safety?
A: Yes. The ABS braking system improves vehicle stability and braking performance.
Q: Can this truck handle different road conditions?
A: Yes. Multiple suspension and tire configurations are available for urban roads, highways, and tougher working environments.
Q: Why choose this FAW cargo truck?
A: It offers strong loading capacity, reliable performance, fuel efficiency, and low operating costs for commercial transport businesses.
