JAC 4×2 Light Duty Wrecker Truck with 3 Ton Slide Bed
- 4200mm slide-bed platform
- 3-ton loading capacity
- 4-ton towing capacity
- Hydraulic winch
- 25m wire rope
- Hydraulic wheel-lift system
- Bilateral linkage operating device
- Fork and fork seat holding mechanism
- Towing mechanism
- Safety chains
- Auxiliary wheels
- Toolbox
- Vehicle securing belts
- LED warning and working lights
Product Description
JAC 4×2 Light Duty Wrecker Truck
The JAC 4×2 Light Duty Wrecker Truck is designed for vehicle recovery, roadside assistance, towing operations, and accident vehicle transport.
Equipped with a 3-ton slide bed, 4-ton towing capacity, hydraulic wheel-lift system, and 25-meter winch cable, this JAC wrecker truck provides a practical solution for recovering disabled vehicles and transporting cars safely.
The compact 4×2 chassis offers good maneuverability on urban roads, narrow streets, parking areas, and roadside recovery locations. The truck is available with left-hand drive or right-hand drive configurations, making it suitable for different international markets.
Product Specifications
| Item | Specification |
|---|---|
| Product Type | Light Duty Wrecker / Recovery Truck |
| Drive Type | 4×2 |
| Steering | LHD / RHD Optional |
| Chassis Brand | JAC |
| Engine Model | CY4102BZLQ |
| Engine Type | Diesel |
| Horsepower | 120 HP |
| Displacement | 3820 cc |
| Transmission | 6-Speed Manual |
| Gearbox Model | WLY6T46 |
| Wheelbase | 3360 mm |
| Overall Dimension | 5980 × 2330 × 2350 mm |
| Gross Vehicle Weight | 4495 kg |
| Curb Weight | 3590 kg |
| Front Axle Capacity | 2.4 T |
| Rear Axle Capacity | 4.2 T |
| Tire Size | 7.50R16 |
| Tire Quantity | 6 + 1 |
| Suspension | Front & Rear Leaf Springs |
| Wrecker Type | Slide Bed with Wheel-Lift |
| Flatbed Length | 4200 mm |
| Flatbed Loading Capacity | 3 T |
| Towing Capacity | 4 T |
| Winch | 1 Unit |
| Wire Rope Length | 25 m |
| Underlift Capacity | 5.5 T / 2.5 T Fully Extended |
| Underlift Capacity | 8.8 T / 4 T Fully Retracted |
| Operation System | Bilateral Linkage Operation |
| Fuel Tank | 120 L |
| Emission Standard | Euro 3 / Euro 4 / Euro 5 / Euro 6 Optional |
| Certification | ISO9000, CCC |
| Condition | New |
| Origin | Hubei, China |
Why Choose This JAC Wrecker Truck?
3-Ton Slide Bed for Vehicle Recovery
The 4200mm slide-bed platform provides a 3-ton loading capacity, allowing disabled and damaged vehicles to be loaded onto the truck for safe transportation.
4-Ton Towing Capacity
The recovery system provides up to 4 tons of towing capacity, making the truck suitable for recovering passenger cars and light commercial vehicles.
Hydraulic Wheel-Lift System
The wheel-lift system allows vehicles to be towed with their wheels lifted from the road, providing greater flexibility for roadside recovery operations.
25-Meter Winch Cable
The 25-meter wire rope provides sufficient working length for pulling disabled vehicles onto the slide bed during recovery operations.
Compact 4×2 Chassis
The compact chassis provides good maneuverability in urban environments, narrow roads, parking areas, and restricted working locations.
LHD and RHD Options
The JAC recovery truck can be left-hand drive or right-hand drive to meet different driving regulations and market requirements.
Reliable Diesel Power
The 120HP diesel engine and 6-speed manual transmission provide practical power for daily vehicle recovery and towing operations.
Standard Recovery Equipment
The standard configuration includes:
- 4200mm slide-bed platform
- 3-ton loading capacity
- 4-ton towing capacity
- Hydraulic winch
- 25m wire rope
- Hydraulic wheel-lift system
- Bilateral linkage operating device
- Fork and fork seat holding mechanism
- Towing mechanism
- Safety chains
- Auxiliary wheels
- Toolbox
- Vehicle securing belts
- LED warning and working lights
Optional Configurations
The JAC wrecker truck , customize according to different market and operational requirements.
Available options include:
- LHD / RHD
- Euro 3 emission standard
- Euro 4 emission standard
- Euro 5 emission standard
- Euro 6 emission standard
- Rear flip plate
- Retractable plate
- Intermediate platform extension
- Full landing platform
- Customized flatbed dimensions
- Customized wheel-lift configuration
- Company logo and color customization
Applications
The JAC 4×2 wrecker truck is suitable for:
- Vehicle Recovery
- Roadside Assistance
- Accident Vehicle Towing
- Towing Companies
- Automotive Repair Workshops
- Car Dealerships
- Municipal Emergency Services
- Highway Roadside Assistance
- Fleet Management
- Vehicle Transport and Recovery
FAQ
What is the maximum towing capacity of this JAC wrecker truck?
The truck has a maximum towing capacity of 4 tons.
What is the loading capacity of the slide bed?
The 4200mm slide bed has a loading capacity of approximately 3 tons.
Does the truck have a wheel-lift system?
Yes. The truck is equipped with a hydraulic wheel-lift system for towing vehicles with their wheels lifted from the ground.
Is the JAC wrecker truck available in right-hand drive?
Yes. Both LHD and RHD configurations are available for different international markets.
What emission standards are available?
Euro 3, Euro 4, Euro 5, and Euro 6 configurations can be provided depending on the selected chassis and destination market.
Can the wrecker truck be customized?
Yes. The flatbed, wheel-lift system, steering position, emission standard, platform configuration, color, and other equipment can be customized according to customer requirements.
How can the truck be shipped?
Depending on the destination and vehicle dimensions, the truck can be shipped by RORO, bulk vessel, or container.
