49.6 CBM LPG Semi Trailer | Factory Good Price Chengli

factory good price chengli Overview.

factory good price chengli is an important factor in commercial vehicle safety.

Introduction.

Chengli manufactures 49.6 cubic meter LPG semi trailers in China. The tank carries liquefied petroleum gas (propane). The tank has a 12mm wall thickness. The trailer is built for flammable gas transport on highways.

The chassis uses a wheelbase of 6800 plus 1320 plus 1320 mm. The overall dimensions are 12740 by 2480 by 3800 mm. The estimated tare weight is 15300 kg. The rated payload is 20832 kg.

Key Features.

The trailer includes full quality inspection and certified pressure vessel construction.

• Q345 steel tanker body, 12mm thickness.
• Overall heat treatment at Not provided in source.
• 100 percent flaw detection on all welds.
• Magnaflux inspection at critical welding points.
• Hydrostatic test pressure of 2.1 MPa.
• Design pressure rated at 1.61 MPa.
• Corrosion allowance of 1mm built into specification.
• Two or three emergency cut-off valves fitted.
• Four to six ball valves for operation.

Performance and Configuration.

The running gear uses three 13-ton BPW axles. The tire specification is 12R22.5 tubeless type. Eight tires are mounted on the trailer. One spare tire is carried for road use. The king pin size is #50 or #90. The JOST landing leg supports the trailer when detached.

The control panel on top includes a liquid gauge, a pressure indicating thermometer, and a pressure gauge. The manual switch type valve has a DN450 size rating. All pressure-bearing materials follow the Q345 standard. The weld joint factor is set to 1 for full integrity.

Applications.

This trailer is designed for liquefied petroleum gas distribution. Propane is the primary product carried. The vehicle serves industrial and commercial gas supply chains. Municipal and regional fuel distributors use this equipment.

The design temperature is Not provided in source. The trailer handles normal highway transport conditions. It is suitable for long-distance domestic delivery routes across China and export markets.

Why Choose This Truck.

Chengli supplies directly from the factory. This gives competitive pricing on every unit. The 49.6 cubic meter capacity meets common transport requirements. The certified pressure vessel construction ensures safety compliance.

Full inspection records are provided. Every weld undergoes flaw detection. The factory offers clear communication and fast delivery. Contact the Chengli factory for current pricing and availability.
