China FAW 4×2 4Tons Tilt Tray Flatbed Towing Truck – Factory Good Price Chengli
FAW 4×2 4-ton tilt tray flatbed tow truck from Chengli factory. 130HP engine, 5000kg max towing weight, 4000kg platform load. Competitive direct pricing.
factory good price chengli Overview.
factory good price chengli is an important factor in commercial vehicle safety.
Introduction.
Chengli offers the FAW 4×2 4-ton tilt tray flatbed tow truck directly from the factory. This recovery vehicle combines a robust FAW chassis with a hydraulic tilting platform designed for light to medium towing operations.
The truck supports a maximum rated towing weight of 5000 kg and a platform load of 4000 kg. Chengli manufactures this unit at competitive pricing for buyers seeking reliable vehicle recovery equipment.
Key Features.
The FAW 4×2 tilt tray truck includes several core towing and recovery features.
- Hydraulic tilt platform with Not provided in source extension travel.
- Planetary winch with 4000 kg pulling power.
- 21-meter steel cable.
- Automatic safe brake if winch or engine fails.
- Control panel with joysticks and hydraulic meters outside the cabin.
- Hydraulic pressure relief and lock valves.
Performance and Configuration.
The FAW chassis uses a 4×2 driving configuration. The 130 HP engine delivers 96 KW of power through a WLY6T115 six-speed manual gearbox with one reverse gear. Maximum road speed reaches 103 km/h.
The overall vehicle measures 7305 by 2380 by 2650 mm. The wheelbase is 3815 mm with a front track of 1504 mm and rear track of 1522 mm. Approach and departure angles are Not provided in source.
The truck rides on 7.50R16 tires. The rear axle is rated at 4.8 tons. The mass in working order is 4800 kg and the gross vehicle weight reaches 7300 kg. Steering uses hydraulic assistance and the parking brake operates with spring energy. The electrical system runs on 24 volts.
The tilt platform measures 5600 by 2350 mm externally. Minimum elevation of the fully extended platform is Not provided in source. The boom has a max effective length of 1700 mm with 1340 mm extension traveling. The winch drum diameter is 11 cm.
Applications.
This tilt tray flatbed tow truck serves vehicle recovery and transport operations. It handles breakdowns, accidents, and off-road recoveries for cars and light commercial vehicles.
The hydraulic tilt system allows easy loading from ground level. The winch provides additional pulling capability when needed on slopes or rough terrain.
Why Choose This Truck.
Chengli supplies this FAW 4×2 tow truck directly from the factory at competitive pricing. Buyers receive a complete recovery vehicle with hydraulic tilt platform, planetary winch, and control panel ready for deployment.
The 5000 kg towing capacity and 4000 kg platform load provide solid capability for light to medium recovery work. The automatic brake system adds operational safety during winch use.
